When a 9-V battery is temporarily short-circuited, a 200-mA...

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Internal Resistance

Internal resistance refers to the inherent opposition to current flow within a battery or any power source. It is a critical parameter because it affects the output voltage, especially under high current loads such as during a short circuit. Knowing the internal resistance is important for understanding how much energy is lost within the battery itself and how the battery will perform in real circuits.

Ohm’s Law

Ohm’s Law is a fundamental principle in electrical engineering which states that the current flowing through a conductor between two points is directly proportional to the voltage across the two points and inversely proportional to the resistance between them. This principle is used to calculate unknown parameters in circuits, including the internal resistance of a battery when the short-circuit current is known.

Battery Modeling

Battery modeling involves representing a battery as an ideal voltage source in series with an internal resistance. This simplified model helps in analyzing the behavior of the battery under various conditions, allowing one to determine how much voltage is dropped due to internal resistance, which can then be used to predict performance in practical applications.
