When a drop of water is placed on a flat, clear surface such as a glass slide or plastic sheet, surface tension pulls the top surface into a curved, lens-like shape so that the drop functions as a simple magnifier. Suppose a drop of water has a maximum angular magnification of 3.50. (a) Find the drop’s focal length. (b) Assuming the bottom surface of the drop is flat, use the lens-maker’s equation from Topic 23 to calculate the radius of curvature of the top surface.

Key Concepts

Planoconvex Lens

A planoconvex lens is a type of lens that has one flat surface and one convex surface. This configuration simplifies the application of the lens-maker’s equation because the flat surface has an infinite radius of curvature, allowing for easier computation of parameters such as the radius of curvature of the curved surface. It is a common model in optics to study the properties of lenses that reduce certain aberrations and provide effective magnification.

Angular Magnification

Angular magnification is the ratio of the angle subtended by the image as seen through an optical device to the angle subtended by the object when seen with the naked eye. In simple magnifiers, this concept quantifies how much larger an object appears, and it is closely linked to the focal length of the lens used, influencing the design and performance of optical instruments.

Focal Length

Focal length is the distance from the lens at which parallel rays of light are brought to a focus. It is a key parameter determining the optical power of a lens. In the context of a simple magnifier, a shorter focal length results in higher magnification, and it is essential for relating the geometry of the lens to its ability to enlarge an object.

Lens-Maker’s Equation

The lens-maker’s equation establishes a relationship between the focal length of a lens, its refractive index, and the radii of curvature of its surfaces. For a thin lens, it is expressed as 1/f = (n - 1)(1/R1 - 1/R2). This equation is fundamental in optics for designing lenses and calculating missing parameters when certain physical and material properties are known.
