Which of the statements below about magnetic induction...

Which of the statements below about magnetic induction tomography (MIT) and transcranial magnetic stimulation (TMS), studied in Section $21.5,$ are true? (a) Both MIT and TMS have source currents in coils, source magnetic fields, and induced currents. (b) MIT detects the induced magnetic field produced by the induced current, and TMS does not. (c) MIT provides information directly about the imaged area, whereas TMS disrupts some brain activity, and the disruption is measured in some other way. (d) a and c only (e) $a, b,$ and $c$

Which of the statements below about magnetic induction tomography (MIT) and transcranial magnetic stimulation (TMS), studied in Section $21.5,$ are true?
(a) Both MIT and TMS have source currents in coils, source magnetic fields, and induced currents.
(b) MIT detects the induced magnetic field produced by the induced current, and TMS does not.
(c) MIT provides information directly about the imaged area, whereas TMS disrupts some brain activity, and the disruption is measured in some other way.
(d) a and c only
(e) $a, b,$ and $c$

Key Concepts

Magnetic Induction Tomography (MIT)

MIT is an imaging technique based on electromagnetic induction. It operates by generating primary magnetic fields with coils, which induce currents in the medium under study. The resulting secondary magnetic fields, produced by these induced currents, are measured to determine properties such as conductivity, allowing for internal imaging of the target object or tissue.

Transcranial Magnetic Stimulation (TMS)

TMS is a non-invasive method that uses magnetic fields generated by coils to induce electric currents in specific areas of the brain. Unlike imaging techniques, its primary purpose is to stimulate or disrupt neural activity, which can then be observed indirectly through changes in brain function or behavior.

Electromagnetic Induction

This fundamental physical principle explains how a changing magnetic field produces an electric current in a conductor. It underpins both MIT and TMS, where coils create magnetic fields that generate currents in nearby conductive materials, whether for imaging or stimulation purposes.

Imaging vs. Stimulation Approaches

The two techniques differ in their goals and measurements. MIT focuses on imaging by directly measuring the induced magnetic fields to infer material or tissue properties, whereas TMS is used to stimulate or disrupt brain activity by inducing currents, with its effects assessed through subsequent physiological or behavioral responses.

Transcript

00:01 So this question is asking us to compare and contrast magnetic induction topography and transcranial magnetic stimulation.

00:10 So mit versus tms.

00:12 And they're asking which statement comparing these two processes are true.

00:18 So let's first quickly review what tms is about.

00:23 So suppose you have a patient and you want to.

00:30 Induce a current in a region of the patient's brain.

00:34 So what you do is you put a coil above the patient's brain and of course it's connected to the battery and you have a current running through it.

00:43 Therefore, you have created a magnetic field going through this coil and it's going to go through the patient's skull onto this conductive region in the patient's brain.

00:55 And because you turn on the current in this coil that will cause a changing magnetic field going through this coil.

01:07 In other words, there's going to be a changing magnetic flux, therefore inducing a current going through the, going around in the circular region in the patient's brain.

01:22 So the goal of tms is to sort of produce some effect in the patient's brain to see how the patient would react.

01:35 So that's the process of tms.

01:38 Whereas mit is more about, say, this is the ground, right? you first have a source coil that has a source current.

01:52 And this, of course, would induce magnetic field through the ground.

01:59 And then you will induce a response from the bottom, like in the below ground in the soil, for example.

02:10 And this is going to have an induced current in the ground.

02:14 And this induced current will then, in effect, produce a magnetic field back.

02:21 And then you're going to use another coil to measure this new magnetic field.

02:29 And so in this case, mit is not used to produce an effect in the soil.

02:35 It's not to produce a response from the soil.

02:38 It is there to measure something directly in the soil by having multiple different coils, one producing the magnetic field and one measuring the response magnetic field from the soil that it is measuring.

02:53 So let's read all the statements in the question to see which one would fit what we just discussed.

03:01 So letter a says both mit and tms have source currents in coils, source magnetic fields, and induced currents...
