You are asked to consider a pump geometrically similar to...

You are asked to consider a pump geometrically similar to the 9 -in-diameter Taco pump of Fig. $\mathrm{P} 11.34$ to deliver 1200 gal/min at $1500 \mathrm{r} / \mathrm{min} .$ Determine the appropriate (a) impeller diameter (b) BEP horsepower (c) shutoff head, and (d) maximum efficiency. The fluid is kerosene, not water.

Key Concepts

Fluid Properties

The properties of the fluid being pumped, such as density and viscosity, are critical in pump performance analysis. Since these properties affect the dynamic similarity and scaling of the pump, adjustments must be made when using a fluid other than the standard (often water) to accurately predict performance, particularly in terms of head and power requirements.

Affinity Laws

The affinity laws (or pump scaling laws) describe how changes in pump speed or impeller diameter affect performance parameters like flow, head, and power. These laws provide relationships such as flow rate being proportional to the product of impeller diameter and rotational speed, head proportional to the square of these quantities, and power proportional to the cube, allowing engineers to scale pump dimensions and operating conditions predictively.

Geometric Similarity

This concept refers to designing and scaling pumps so that all dimensions are proportionally related. When pumps are geometrically similar, key performance parameters such as flow rate, head, and power can be predicted through scaling laws. This ensures that the overall behavior of the fluid flow and mechanical interaction stays consistent even when the size of the pump changes.

Pump Performance Metrics

Key performance metrics such as impeller diameter, shutoff head, Best Efficiency Point (BEP) horsepower, and maximum efficiency are central to pump design and analysis. Understanding these metrics is essential for ensuring that a pump will perform optimally under specified operating conditions, and they are typically derived from and verified by pump performance curves.
