You want to measure simultaneously the potential difference...

You want to measure simultaneously the potential difference across and the current through a resistor, $R$. As the circuit diagrams show, there are two ways to connect the two instruments -ammeter and voltmeter-in the circuit. Comment on the result of the measurement using each configuration.

Key Concepts

Loading Effect and Circuit Perturbation

Even though instruments are designed to be close to ideal, their non-ideal internal resistances can still affect circuit measurements. This phenomenon, commonly referred to as the loading effect, occurs when connecting a measurement device alters the conditions in the circuit. For example, a voltmeter with finite resistance connected in parallel with a resistor can change the effective resistance seen by the source, thereby impacting current flow and voltage distribution, and ultimately the accuracy of both voltage and current measurements.

Series vs. Parallel Instrument Connections

The configuration of measurement instruments in a circuit is crucial. An ideal set-up involves placing the ammeter in series with the load to accurately measure the current and the voltmeter in parallel across the load to measure the voltage. If instruments are not connected correctly—such as inadvertently placing a voltmeter in series, or using a connection that allows the voltmeter to shunt the load—the resulting measurement can be compromised due to the unintended alteration of the circuit's resistance and current distribution.

Ammeter and Voltmeter Characteristics

In circuit measurement, ammeters are designed to have very low internal resistance so they can be inserted in series with a load without significantly changing the current flow, while voltmeters are built to have very high internal resistance so that when connected in parallel they do not draw appreciable current from the circuit. These characteristics are essential in ensuring that each instrument minimally disturbs the circuit parameters it is meant to measure.
