Q2:
A certain force F applied at D near the end of the 15 -in lever shown in Fig, which is quite similar to a socket wrench, results in certain stresses in the cantilevered bar \( \mathrm{OABC} \). The bar OABC is of AISI 1035 steel, forged and heat treated so that it has a minimum (ASTM) yield strength of \( 81 \mathrm{Kpsi} \). Presume that this component would be of no value after yielding. Thus the force \( F \) required to initiate yielding can be regarded as the strength of the component part. Compute the maximum force that can be safely applied, based on Maximum-Shear-Stress Theory, for the stress at point A. (10 Marks)
