1. Noninverting amplifier
Using one of the op amps from the LM 324 array, build the noninverting amplifier circuit shown on the right. Measure the resistors, so that you know their precise values.
For $v_s$, use the function generator set to a sinusoid with frequency of 1000 Hz and amplitude of 0.5 $V_{RMS}$.
Then follow the steps outlined below.
a. Calculate the expected gain, $G = v_o/v_s$ for the circuit.
