I need help with exercise7.44 the tension bracket. Can you draw the front, top, and right view, with the measurements in inches please.
CHAPTER EXERCISES
317
"Sketch or draw necessary views. Larger and more detailed parts show the details more clearly when drawn on larger sheet sizes. Consider using B, C, or A3 or A 2 sheets. Use a title block or title strip as assigned by your instructor. If dimensions are required, study Chapter 11 and use metric or decimal-inch dimensions as assigned by your instructor. Move dimensions to better locations where possible.
