QUESTION 8
The figure below shows a circuit whose elements have the following values:
?? = 3.0 V, ?? = 6.0 V, R? = 2.0 ?, R? = 4.0 ?. The three batteries are ideal batteries. Find the
magnitude
of the current in each of the three branches
A. $i_1 = 0.5A$, $i_2 = 0.25A$, $i_3 = 0.25A$
B. $i_1 = 0.25A$, $i_2 = 0.5A$, $i_3 = 0.25A$
C. $i_1 = 0.25A$, $i_2 = 0.25A$, $i_3 = 0.5A$
