Consider the following catalogue segment for different types of ACSR conductors used in high
voltage AC transmission network.
DC
AC
Geometric
Reactances
Resistance
Resistance
Stranded
Mean
Conductor
(ohms/km) (ohms/km)
(ohms/mile)
Radius
at
at
at
20°C 20°C 75°C
(mm)
inductive capacitive
ACSR-1
0.189 0.196 0.240
7.22
0.432
0.0992
ACSR-2
0.125
0.136 0.167
8,66
0.430
0.0988
ACSR-3
0.104
0.116 0.142
9.38
0.424
0.0980
ACSR-4
0,082
0,100 0,123
10,11
0,432
0,0981
ACSR-5
0.045
0.076 0.097
10.93
0.423
0.0969
For the ACSR conductor given in the row number 3, calculate the magnitude of the total series
impedance in ohms at 35 celcius degree temperature if the length of this conductor is 94 miles.
Assume that the operation frequency is equal to the one considered in the catalogue.
