Vin
For the circuit below, evaluate the stability steady-state error, time response analysis,
frequency response, and change in stability with different values of gain. Show all your
work by calculations and use of MATLAB. R₁ = 125 MΩ, C₁ = 15µF, R₂ =
625MΩ, C₂ = 0.1μF. The system is cascaded with a system that is designed to
give a steady-state error for a certain value of K where its G(s) =
for
K
(s+5)(s+15)
CNS117V Project 1
ess = 10^-2 then plugged into a negative unity feedback system.
C₁
PROJECT I
اب
www
R₁
R₂ C₂
www
October 2023
Fig 1
R₂
R₂
+
Vout
