2 resistor, 1 capacitor circuit
some dc
R1
R2
input is a
Square wave
1. Please create a problem where you use this
2R1C circuit and send a square wave through
with values that you plug in, the sketch the resulting
waveform and show where DC lies on the
wave form, please show all of your work.
thank you!!
(make up your own values for
all variables)
