Question 2: There is 0.7 kg water in the closed piston-cylinder initially at
300 kPa and 200°C. Heat is constantly removed from the cylinder. The piston
moves freely until it hits the stops. At this point, the water in the cylinder
has a quality 0.85. If heat is further removed from the cylinder until the
pressure drops to 175 kPa, (a) calculate the final volume of water, and (b) the
final mass of the liquid phase. (50 points)
water
M = 0.7 kg
V_2 = ?
M_2 = ?
P_2 = 175 kPa
P = 300
T_1 = 200°C
0.85
