A cylindrical specimen of an AISI-SAE type 416 stainless steel with a 0.505-inch diameter tensile bar is machined to a 2.00-inch gage length. After fracture, the gage length is 2.20 inches and the diameter is 0.325 inches.
a. Plot the engineering stress-strain curve.
b. Determine the following properties: modulus of elasticity, proportional limit, 0.2% offset yield strength, and tensile strength.
c. Using the final values measured at the conclusion of the test, calculate the ductility in terms of % elongation and % reduction in area.
d. Determine the elastic and plastic strain to fracture.
Load (lbs) Gage Length (in)
0 2.000
2,850 2.001
5,710 2.002
8,560 2.003
11,400 2.004
17,100 2.006
20,000 2.008
20,800 2.010
23,000 2.015
24,200 2.020
26,800 2.030
28,800 2.040
33,650 2.080
35,750 2.120
36,000 2.140
35,850 2.160
34,050 2.200
28,000 2.230
