Determine the shear and moment diagrams for the loaded cantilever beam. Then answer the questions. The distance x is measured
from point A to the right.
520 N/m
5.0 m
9 m
Questions:
At x = 2.8 m, V = 2600 N, M = -9620 N-m
At x = 6.9 m, V = 0 N, M = 11445.2 N-m
The maximum (absolute value) shear force is 2600 N
The maximum (absolute value) bending moment is 9620 N-m
