Date:
Determine if the output signal from the amplifier described below will exhibit Slew Rate distortion,
clipping distortion, and/or bandwidth limitations for the Slew Rate and Unity Gain Bandwidth
parameters provided. Assume the amplifier needs to provide full output voltage at 510k hertz. Show All
work in an organized format! Label the computations for each justification accordingly in the work space
provided!
Given:
Es = 500 milli-volts p-p, Es is sinusoidal
SR = 6 v/us
Large Signal Voltage Gain = 225 v/mv
$t_r$ = 25 us
$|V_E| = |V_C| = 15v
Avymid = $v_o/v_{in}$=
Avymid dB =
Voutput p-p (full power, ideal) =
Voutput p-p maximum for SR and
frequency specified =
Will Voutput exhibit SR Distortion?
Justify your answer.
Does Voutput exhibit Clipping
Distortion?
Justify your answer:
GBW =
f$_r$ =
Av$_v$ @ f$_r$ =
Av$_v$ dB @ f$_r$ =
Voutput p-p @ f$_r$ =
Will Voutput exhibit a Bandwidth
Limitation @ f$_{signal}$ = 510k hertz?
Justify your answer.
What is the maximum frequency of
Voutput at which full power
bandwidth will be observed?
Justify your answer:
