Q2. Realize the Boolean function F(A,B,C,D)=?(1,2,3,5,7,8,14)
by using a 8x1 MUX. (25p)
a) Construct the implementation table as shown below..
b) Determine the values of the inputs I0... I7 and draw the implementation circuit diagram.
Io I1 I2 I3 I4 I5 I6 I7
Do
D1
