Design a basic desk and chair and sketch hand drawings. These drawings should be clear enough that someone could build this set easily. The following conditions must be met:
- The chair should have a minimum of 6 parts (4 legs, seat, back).
a. If all legs are the same, only need to draw it once.
- The desk should have a minimum of 5 parts (4 legs, top).
a. If all legs are the same, only need to draw it once.
- Additionally, add a desk accessory (pencil holder, etc... Be Creative!) that is included with your drawing package.
- The components should be assembled in some way (screws or epoxy/glue) depending on your design. If you use screws, use the internet (Lowes.com, Homedepot.com, etc.) to find a good type/length for your application. If you use epoxy or glue, take that into consideration in your design.
- A full parts list should be included, including material of each component and screws.
- Each drawing should have a title block that includes the following:
a. A company name (make one up!)
b. Drawing Title
c. Drawing Number
d. Revision Number
e. Drafted By
f. A general tolerance (could vary based on your material of construction). You do NOT have to do tolerances for individual dimensions.
- Isometric is NOT required for each part.
