Q1. (a) Write the mathematical expression for the waveform as in Figure S1-Q1 in
terms of the unit step and ramp functions.
x(t)
2
1
0
1
2
3
4
t
Figure S1-Q1
(b) Sketch the signal $r(t)$ given by
$\frac{3}{5}[1 - \text{rect}(\frac{t}{2} - 3)]u(t)$
(c) Using the given signal $r(t)$ and $x(t)$, sketch the following signals.
(i) $p(t) = -2x(-2t - 4)$
(ii) $s(t) = -r(-t) + 0.6$
