Multiple Choice
Circle the correct answer.
1. What is the maximum number of lines you can draw at the same time
with Multiline?
a. 2 c. 12
b. 4 d. 16
2. Which of the following Multiline justification options can you use to
draw a three-line multiline that has a 3 offset, a 0, and a -3 offset,
using the middle line?
a. Top c. Zero
b. Right d. Left
3. When you have created a new multiline style, what must you pick in the
Multiline Style dialog box to set the new style current?
a. Set Current c. Save...
b. Load d. Add
4. Which of the following must you select first when using the EXTEND
command?
a. The correct layer c. Object to extend
b. The correct color d. Boundary edge
5. Which of the following may not be changed with the PROPERTIES
command?
a. Color c. Layer
b. Linetype d. Drawing name
6. Which of the following commands tells you the layer a line is on and its
length?
a. Status c. DIST
b. LIST d. Area
9780136787884_print.indb 291 07/09/21 3:35 PM
292 Part Two | Two-Dimensional AutoCAD
7. If you insert a block with the Explode check box select in the Insert
dialog box, which of the following is true?
a. The block must be exploded before it can be edited.
b. Each element of the block is a separate object.
c. AutoCAD will not accept the block name.
d. The block comes in smaller than originally drawn.
8. The WBLOCK command does which of the following?
a. Creates a drawing file on any disk, drive, or network
b. Creates a drawing on the hard drive only
c. Creates blocks of parts of the current drawing only
d. Uses only named blocks on the current drawing
9. Which scale factor can you use to create a mirror image of a block with
the Insert command?
a. Negative X, Negative Y
b. Positive X, Positive Y
c. Negative X, Positive Y
d. Mirrored images cannot be created with the Insert command.
10. Which of the following commands attaches a paintbrush to the cursor
so you can copy properties from one object to another?
a. Match Properties c. Make Object’s Layer
Current
b. Copy Prop d. PROPERTIES
