QUESTION 9
Find the equivalent resistance, $R_{eq}$ of $R_1$ and $R_2$, in the circuit below, given that $R_0 = 50\Omega$, $R_1 = 50\Omega$, $R_2 = 500\Omega$.
$V_{source}$
$V_{in}$
$R_0$
$R_1$
$R_2$
$R_{eq}$
$V_{out}$
a. $R_{eq} = 510\Omega$
b. $R_{eq} = 49.5\Omega$
c. $R_{eq} = 505\Omega$
d. $R_{eq} = 99.5\Omega$
