series AC circuit contains a resistor, an inductor of 230 mH, a capacitor of 4.40 µF, and a source with ΔVmax = 240 V operating at 50.0 Hz. The maximum current in the circuit is 180 mA.
(a) Calculate the inductive reactance.
Ω
(b) Calculate the capacitive reactance.
Ω
(c) Calculate the impedance.
kΩ
(d) Calculate the resistance in the circuit.
kΩ
(e) Calculate the phase angle between the current and the source voltage.
°
