4. The Figure 2 shows a shaft mounted in bearings at A and D and having pulleys at B and C. The forces shown acting on the pulley surfaces represent the belt tensions. The shaft is to be made of steel with yield strength 220 MPa using a factor of safety = 2, determine the diameter of the shaft to avoid yielding, use a conservative failure theory.
Figure 2: Shaft under combined loading
