In this exercise, we will implement binary addition. You must implement the actual rules of binary addition.
When adding binary numbers, each column has three inputs and two outputs. The inputs are:
c = Carry From Last Column (Initially 0)
a = Current Bit of First Number
b = Current Bit of Second Number
The outputs are:
o = Carry for next Column
r = Bit of Result Number
There are a total of 8 possible cases for each column:
c + a + b = o r
0 + 0 + 0 = 00
0 + 0 + 1 = 01
0 + 1 + 0 = 01
0 + 1 + 1 = 10
1 + 0 + 0 = 01
1 + 0 + 1 = 10
1 + 1 + 0 = 10
1 + 1 + 1 = 11
If we want to add 4 (0100) and 5 (0101), then we need to do 4 additions:
c + a + b = o r
0 + 0 + 1 = 01
0 + 0 + 0 = 00
0 + 1 + 1 = 10
1 + 0 + 0 = 01
The result is 1001. If the last carry value is 1, this is called an overflow. If this happens, the carry is truncated because there are no more bits to fit it.
Copy your getStr(question) function from part B for use here.
Implement binarySum(X,Y) that computes the sum of two binary strings. You may assume both inputs are strings containing only the characters "0" and "1". You do not need to error check this.
The two input strings must have the same length. If they have different lengths, return "Cannot Add!".
Add the numbers using the binary logic described above. You may not convert the numbers to/from integers. You must use the logic for binary addition described above in your function.
Develop a main function that asks the user for two binary numbers and prints their sum. Repeat until the user tells you to exit.
Welcome to Binary Adder
Enter "exit" to quit at any time.
Enter first Binary Value:
0100
Enter Second Binary Value:
0101
Sum: 1001
Enter first Binary Value:
11111110
Enter Second Binary Value:
00000101
Sum: 00000011
Enter first Binary Value:
0100
Enter Second Binary Value:
11111
Sum: Cannot Add!
Enter first Binary Value:
01001110
Enter Second Binary Value:
01011011
Sum: 10101001
Enter first Binary Value:
0010011010010001
Enter Second Binary Value:
0000010010110001
Sum: 0010101101000010
Enter first Binary Value:
exit
