Preamble
This lab has two parts to it. The first involves problem solving and can be completed on paper (or digitally). In either case, make sure your writing is LEGIBLE. If I can’t read it, I can’t mark it. The second part involves writing C programs that send and catch signals.
Lab Description – Part I
1) Consider the hypothetical processor with instruction format seen below:
In class, we saw an example that considered three instruction opcodes. For this question, we add two more for a total of five. The full set of opcodes, in binary, is as follows:
0001 = Load AC from memory
0011 = Load AC from I/O device
0010 = Store AC to memory
0111 = Store AC to I/O device
0101 = Add to AC from memory
For the new opcodes 0011 and 0111, the address field in the instruction refers to some external I/O device. Show the execution for a program that does the following:
1. Load AC from device 5 (address 705).
2. Add contents of memory location 305.
3. Store AC to device 6 (address 706).
In your answer, it is enough to show the contents of the registers at each step. The initial state of the CPU, in the same format we saw in class, can be seen in the first fetch stage on the next page. You must fill in the memory and register values for this initial fetch stage and all remaining instruction cycles. Use Hexadecimal digits when filling in the stages.
