Design of Slider-Crank Mechanisms
For Problems, design a slider-crank mechanism with a time ratio of Q, stroke of ($CR_4$) max and time per cycle of t. Use either the graphical or analytical method. Specify the link lengths L2, L3, offset distance L1 (if any), and the crank speed.
Q = 1; $|CR_4|_{max} = 8 \text{ mm}; t = 0.08 \text{ s}.$
