Q 3(e)
An engine operates on the simple ideal Brayton cycle where air is used as the working
fluid. The pressure ratio is 12, with a compressor inlet temperature of 300K and a
turbine inlet temperature of 1000K. Determine:
i. The output of the turbine where it operates isentropically.
[3 Marks]
ii. The output of the compressor where it operates isentropically.
[3 Marks]
iii. The required mass flow rate of air for a net power output of 70 MW, assuming
both the compressor and the turbine are isentropic.
[5 Marks]
iv. The required mass flow rate of air for a net power output of 70 MW, assuming
both the compressor and the turbine have an isentropic efficiency of 85 percent.
[5 Marks]
Assume constant specific heats at room temperature
[End of Question 3]
