a. You are given 4-to-1 multiplexers as building blocks. Implement an 8-to-1 multiplexer with these blocks: obtain the schematic, show select inputs S2, S1, S0, and data inputs D7, ...D0. All unused inputs (if any) have to be connected to appropriate static levels (Vdd, GND).
b. Implement the comparator of two 2-bit numbers A1A0 and B1B0 using an 8-to-1 multiplexer, an inverter is available. The circuit has 4 inputs: A1, A0, B1, B0, and one output F. The variant of output function F is defined by the last digit of your ID number as follows:
case 1, your digit is 0, 1, or 2: F = 1 if A1A0 is greater than B1B0, otherwise F = 0,
case 2, your digit is 3 or 4: F = 1 if A1A0 is less than B1B0, otherwise F = 0,
case 3, your digit is 5 or 6: F = 1 if A1A0 is greater or equal to B1B0, otherwise F = 0,
case 4, your digit is 7, 8, or 9: F = 1 if A1A0 is less or equal to B1B0, otherwise F = 0.
Show only one implementation for the function corresponding to your last ID digit.
c.
