1c) A stepped tension bar of circular cross section with shoulder fillet has dimensions D = 30 mm, d = 24 mm and r = 3 mm. Yield stress of the material, $\sigma_y$, is 250 MPa. Determine stress concentration factor using the appropriate chart and with a safety factor of 1.5, determine the maximum allowable tensile force.
