2. A 13.2kV single phase generator supplies power to a load through a transmission line. The load's impedance is $Z_{load} = 500 \angle 36.87^\circ \Omega$ and the transmission line's impedance is $Z_{line} = 60 \angle 53.1^\circ \Omega$. $60 \angle 53.1^\circ \Omega$ $Z_{line}$ 1:10 10:1 $500 \angle 36.87^\circ \Omega$ $V_G = 13.2 \angle 0^\circ kV$ $Z_{load}$ $T_1$ $T_2$ a. Calculate the load current, line current and source current. (without using per unit system) b. Draw the per unit system by considering $S_{base} = 100kVA$ and $V_{base} = 132kV$ in the transmission line section. c. By using the per unit system, find the quantities mentioned in part 'a' and compare them with the results of that part.

          2. A 13.2kV single phase generator supplies power to a load through a transmission line.
The load's impedance is $Z_{load} = 500 \angle 36.87^\circ \Omega$ and the transmission line's impedance
is $Z_{line} = 60 \angle 53.1^\circ \Omega$.
$60 \angle 53.1^\circ \Omega$
$Z_{line}$
1:10
10:1
$500 \angle 36.87^\circ \Omega$
$V_G = 13.2 \angle 0^\circ kV$
$Z_{load}$
$T_1$
$T_2$
a. Calculate the load current, line current and source current. (without using per unit
system)
b. Draw the per unit system by considering $S_{base} = 100kVA$ and $V_{base} = 132kV$ in the
transmission line section.
c. By using the per unit system, find the quantities mentioned in part 'a' and compare them
with the results of that part.

2. A 13.2kV single phase generator supplies power to a load through a transmission line.
The load's impedance is Zload = 500 ∠ 36.87^∘Ω and the transmission line's impedance
is Zline = 60 ∠ 53.1^∘Ω.
60 ∠ 53.1^∘Ω
Zline
1:10
10:1
500 ∠ 36.87^∘Ω
VG = 13.2 ∠ 0^∘ kV
Zload
T1
T2
a. Calculate the load current, line current and source current. (without using per unit
system)
b. Draw the per unit system by considering Sbase = 100kVA and Vbase = 132kV in the
transmission line section.
c. By using the per unit system, find the quantities mentioned in part 'a' and compare them
with the results of that part.
