2. A spur gear of the 14 1/2 degree involute system has a module of 8 mm and 35 teeth. Find a. The pitch diameter b. The circular pitch c. The outside diameter (addendum diameter)

          2. A spur gear of the 14 1/2 degree involute system has a module of 8 mm and 35 teeth. Find
a. The pitch diameter
b. The circular pitch
c. The outside diameter (addendum diameter)

Added by Amanda B.

University Physics with Modern Physics

Hugh D. Young 14th Edition

Instant Answer

Solved by Expert Pranay Shrivastava

Step 1

The pitch diameter can be calculated using the formula: Pitch diameter = Module x Number of teeth Pitch diameter = 8 mm x 35 teeth Pitch diameter = 280 mm b. The circular pitch can be calculated using the formula: Circular pitch = π x Module Show more…
