Question

1. In the following table the activities with their precedence sequence and expected time (days) are listed for a project XYZ company is working: Activity | Immediate Predecessors | Time (days) --- | --- | --- A | - | 3 B | A | 2 C | - | 5 D | B | 6 E | B | 7 F | C | 5 G | D | 6 H | E,F | 2 I | G,H | 5 Draw an AON Diagram: 10 points Diagram must have forward and back pass and show the notations of LS, LS, EF, LF as shown – you can use a separate piece of paper for each drawing or insert a picture in this space. a. Time for team to complete is days. 1 points b. Critical path(s) provide letters . 2 points 2. In the following table the activities with their precedence sequence and expected time (days) are listed for a project: Activity | Immediate Predecessors | Time (days) --- | --- | --- A | - | 6 B | A | 3 C | A | 4 D | B | 2 E | C | 6 F | C | 2 G | E,F | 3

          1. In the following table the activities with their precedence sequence and expected time (days) are listed for a project XYZ company is working:

Activity | Immediate Predecessors | Time (days)
--- | --- | ---
A | - | 3
B | A | 2
C | - | 5
D | B | 6
E | B | 7
F | C | 5
G | D | 6
H | E,F | 2
I | G,H | 5

Draw an AON Diagram: 10 points
Diagram must have forward and back pass and show the notations of LS, LS, EF, LF as shown – you can use a separate piece of paper for each drawing or insert a picture in this space.

a. Time for team to complete is __________ days. 1 points
b. Critical path(s) provide letters __________. 2 points

2. In the following table the activities with their precedence sequence and expected time (days) are listed for a project:

Activity | Immediate Predecessors | Time (days)
--- | --- | ---
A | - | 6
B | A | 3
C | A | 4
D | B | 2
E | C | 6
F | C | 2
G | E,F | 3

1. In the following table the activities with their precedence sequence and expected time (days) are listed for a project XYZ company is working:

Activity | Immediate Predecessors | Time (days)
— | — | —
A | - | 3
B | A | 2
C | - | 5
D | B | 6
E | B | 7
F | C | 5
G | D | 6
H | E,F | 2
I | G,H | 5

Draw an AON Diagram: 10 points
Diagram must have forward and back pass and show the notations of LS, LS, EF, LF as shown – you can use a separate piece of paper for each drawing or insert a picture in this space.

a. Time for team to complete is days. 1 points
b. Critical path(s) provide letters . 2 points

2. In the following table the activities with their precedence sequence and expected time (days) are listed for a project:

Activity | Immediate Predecessors | Time (days)
— | — | —
A | - | 6
B | A | 3
C | A | 4
D | B | 2
E | C | 6
F | C | 2
G | E,F | 3
