3. A bracket is attached to a steel channel by means of nine identical rivets as shown in Fig. 3. Determine the diameter of rivets, if the permissible shear stress is 60 N/mm². $P = 60 kN$ Figure 3
Added by Katie W.
Close
Step 1
Since there are nine rivets, the force per rivet is: $F_{rivet} = \frac{60 \times 10^3}{9} N = \frac{20000}{3} N$ Show more…
Show all steps
