4.11 Find a realization for the proper rational matrix \begin{equation} \hat{G}(s) = \begin{bmatrix} \frac{2}{s+1} & \frac{2s-3}{(s+1)(s+2)} \\ \frac{s-2}{s+1} & \frac{s}{s+2} \end{bmatrix} \end{equation}

          4.11 Find a realization for the proper rational matrix
\begin{equation*}
\hat{G}(s) = \begin{bmatrix}
\frac{2}{s+1} & \frac{2s-3}{(s+1)(s+2)} \\
\frac{s-2}{s+1} & \frac{s}{s+2}
\end{bmatrix}
\end{equation*}
