4. P Ly I Req 4? 5? 5? 3? 5? • 5? 7? 5? 5? 6? + Vx (A) Determine the value for $R_{eq}$, which is the equivalent resistance looking into the terminal pair P-Q. Show your work. (6 pts). (B) If a 6V independent DC voltage source is connected to the terminals P and Q as indicated in the diagram, determine the value for $V_x$. (4 pts) P + 6V Q
