A three-phase balanced load has impedance per phase of ZY=8+j6 ?. If the load is connected to 208V lines, predict the readings of the wattmeters W1 and W2. Find PT and QT. Power measurement is done using 2 wattmeter method.
Added by Sara T.
Close
Step 1
The line voltage is given as 208V. For a balanced three-phase system, the phase voltage is equal to the line voltage divided by the square root of 3. So, the phase voltage is 208V/√3 = 120V. The impedance per phase is given as Zy = 8 + j6. The magnitude of this Show more…
Show all steps
