Adjacency matrices and graphs
Figure 2: An undirected graph with n = 5 vertices.
For a given undirected graph G with no self-loops and at most one edge between any pair of nodes (i.e., a simple graph), as in Figure 2, we associate a n x n matrix A, such that
Aij = { 1 if there is an edge between node i and node j, 0 otherwise.
This matrix is called the adjacency matrix of the graph. The graph in Figure 2 has adjacency matrix
A = [ 0 1 0 1 1 ; 1 0 0 1 1 ; 0 0 0 0 1 ; 1 1 0 0 0 ; 1 1 1 0 0 ] .
1. (2 points) Prove the following result: for positive integer k, the matrix Ak has an interesting interpretation: the entry in row i and column j gives the number of walks of length k (i.e., a collection of k edges) leading from vertex i to vertex j. Hint: prove this by induction on k, and look at the matrix-matrix product Ak-1 A.
2. (2 points) A triangle in a graph is defined as a subgraph composed of three vertices, where each vertex is reachable from each other vertex (i.e., a triangle forms a complete subgraph of order 3). In the graph of Figure 2, for example, nodes {1, 2, 4} form a triangle. Show that the number of triangles in G is equal to the trace of A3 divided by 6. Hint: For each node in a triangle in an undirected graph, there are two walks of length 3 leading from the node to itself, one corresponding to a clockwise walk, and the other to a counter-clockwise walk.
