3. An off-axis lamina is loaded under biaxial compression $\sigma_x = 2\sigma_y = - \sigma_0$ as shown. Calculate the ultimate value $\sigma_0$, using the maximum strain theory for the AS4/3501-6 carbon/epoxy with the following materials properties: $E_1$=147 GPa, $E_2$=10.3 GPa, $G_{12}$=7.0 GPa, $\nu_{12}$=0.27. X=2280 MPa, Y=57 MPa, S=76 MPa, X'=1725 MPa, Y'=228 MPa
