Hi there.
00:03
In this question, we are looking at some lewis electron dot structures.
00:09
And for a structure to be correct, two things need to be satisfied.
00:14
It needs to have the correct number of valence electrons, which are represented in dot structures as dots.
00:24
And each atom needs an octet, with some atoms having an expanded octet, meaning it could have more than eight for certain atoms.
00:49
All right, so let's look at what we have here.
00:51
Our first one is for sf4.
00:53
And to tell if these structures are correct, one of the things we need to do is determine how many valence electrons we have to work with.
00:59
Sulfur is in group six of the periodic table, so it has six valence electrons.
01:06
Each flooring, being a halogen in group seven, each flooring has seven.
01:10
And there are four fluorins, so four times seven is 28.
01:14
Add that to six, we get a total of 34 valence electrons.
01:20
Okay, so that brings us to the structure that they give us.
01:23
They give us sulfur with four bonds.
01:26
That's two, four, six, eight electrons, and then another pair on the sulfur for 10.
01:33
This fluorine has six more, so that's 16.
01:38
This fluorine has six more.
01:40
That's 22, 28, 29, 30, 31, 32, 33, and 34.
01:50
So we have the correct number of dots, and each element has an octet except for the sulfur.
02:01
And sulfur can have more than an octet.
02:05
It can have what's called an expanded octet.
02:08
We said it has 10 electrons around it.
02:13
Therefore, this is a reasonable structure.
02:26
It would be wrong if we put more than 8 around flooring, because flooring cannot have more than an octet.
02:33
Because it does not have any de -orbital to stick some extra electrons in.
02:37
But sulfur can.
02:40
All right.
02:41
So that one is correct.
02:42
Let's look at the next one.
02:44
The next one, we have c -l -o -3 with a negative charge.
02:50
It's a polyatomic ion.
02:52
So chlorine is a halogen.
02:53
It's in group 7a.
02:54
It has seven electrons.
02:56
Each oxygen is in group 6a.
02:59
So each of those has six.
03:00
And then we have to add one electron for that unit of negative charge.
03:06
So we have 7 plus 18, is 25 plus 1 gives us 26.
03:13
So we need 26 valence electrons or 26 dots...
