Required Information Consider the given beam and loading where P= 350 N. E 75 mm F B A C D P P 200 mm 200 mm 200 mm Determine the maximum absolute value of the bending moment. (Round the final answer to two decimal places.) The maximum absolute value of the bending moment is N-m.

          Required Information
Consider the given beam and loading where P= 350 N.
E
75 mm
F
B
A
C
D
P
P
200 mm 200 mm 200 mm
Determine the maximum absolute value of the bending moment. (Round the final answer to two decimal places.)
The maximum absolute value of the bending moment is N-m.
