00:01
This is the answer to chapter four, problem number 41, from the smith organic chemistry textbook.
00:08
And in this problem, we are given many iupac names and asked to draw the molecule for each of these.
00:17
And so just a heads up, this is going to be a bit of a longer answer than usual.
00:23
There's quite a few names that we're given.
00:25
And so i am just going to start drawing them out.
00:28
And so remember the way to approach this, the end of an iupac name tells us either the longest carbon chain or the biggest ring.
00:39
If there's a ring that's bigger than any of the carbon chain is present.
00:43
And so that's a good place to start.
00:46
Start with that base name.
00:47
Again, that's the end of the name.
00:49
And then use the rest of the name to fill in some information about substituents.
00:56
So for a, we have three ethyl -2 methyl -methal.
00:58
Hexane.
01:00
And so, again, the end of the name tells us this is a hexane derivative.
01:04
So we can go ahead.
01:07
Six.
01:08
There's a hexane.
01:09
And then again, it's three ethyl two methyl.
01:12
So one, two, ethel, two methyl.
01:18
So there we go.
01:19
There's three ethel, two methyl hexane for a.
01:22
And so that's that's the way that i'm going to solve these.
01:26
I'm going to look at the end of each iupac name.
01:29
Use that to determine.
01:31
The base chain or the base ring, and then use the rest of the name to fill in the substituents.
01:39
Okay, so that was a.
01:40
B, we have secbutylopentane.
01:45
So cyclopentane is the base name here.
01:49
So five -membered ring, cyclopentane.
01:53
And then on any of these carbons, we can draw a sec -butal group.
02:01
So i don't like the way that looks.
02:03
So there we go.
02:05
Better secbutyl group.
02:06
Okay.
02:07
And again, it could be any carbon because we're not given a number or anything.
02:12
And really, there's no way to number it because all the carbons are equivalent until we put a substituentine.
02:18
So that's secbutyl cyclopentane.
02:22
So then looking at c, we have four isopropyl two, four, five, trimethal heptane.
02:28
Okay.
02:29
And so again, heptane is the base name here.
02:32
So one, two, three, four, five, six, seven.
02:35
Then let's see, four, isopropyl, two, four, five, trimethyl heptane.
02:40
So i like to go left to right whenever possible.
02:44
So this will be carbon two.
02:45
There's a methyl.
02:46
Carbon four, there's a methyl.
02:49
Carbon five, there's a methyl.
02:51
And then four isopropyl.
02:53
So actually, let me back up a little bit.
02:55
So there's one on carbon five.
02:58
There's one on carbon four.
03:00
And then here is our is our isoproble group also on carbon four.
03:06
Okay, and that's four isoproble 245 trimethal heptane.
03:10
So then d is going to be cyclobutyl cyclo -heptane.
03:15
Okay, so this is a seven -membered ring with a four -membered ring attached to it.
03:23
Okay, seven -membered rings are always a struggle to draw.
03:29
I like to pretend that i'm drawing a six -membered ring.
03:34
And then instead of bringing the last two sides together, as i would for a six -membered ring, i bring each of them down only a little bit and then put a connecting piece between them.
03:47
So that's how i do it.
03:49
That's not a great looking.
03:51
There we go.
03:51
That's a little better.
03:52
So there's our cyclo -heptane.
03:54
And then anywhere we can put a cyclobutane.
04:02
So there we go.
04:03
There's d.
04:05
E is going to be 3 -ethyl -1 -1 -dymethyl cyclohexane.
04:11
So we need to draw a cyclohexane to get started.
04:21
So draw a hexagon.
04:23
And then it's 3 -ethyl -1 -1 -dymethyl.
04:27
So we can pick any of these carbons to call 1.
04:30
So i'll start here.
04:31
So this is carbon 1.
04:33
That makes this carbon 3...
