Electrical Engineering Department Question No. 2: [2.5 Marks] Consider the circuit shown in Figure 2.1 below, then apply the Superposition Theorem to find: a. The current $I_2$. b. The voltage drop $V_2$. $R_1 = 330 \Omega$ $E_2 = 10V$ $E_1 = 15V$ $R_2 = 680 \Omega$ $R_3 = 200 \Omega$ Figure 2.1
