          Experiment CK1: Thevenin's Theorem and Superposition Theorem
1.0 Objectives
To verify the Thevenin's theorem by using circuit theory experiment board.
To verify superposition theorem.
2.0 Introduction
Thevenin's theorem is a very useful and frequently used theorem in circuit analysis. To verify Thevenin's theorem, consider a load resistor, R_(L) (or load impedance, Z_(L) ) that is connected to a "black box" as shown in Figure 1. The black box can contain any combination of the circuit elements. Thevenin's theorem states that insofar as the load resistor, R_(L) (or load impedance, Z_(L) ) is concerned, the black box can be represented by a series combination of an ideal voltage source, V_(TH), and a resistor, R_(TH) (or impedance, Z_(TH) ). V_(TH) is known as the Thevenin's equivalent voltage source. Its value can be found by measuring the open-circuit voltage between terminals x and Y when the resistor, R_(L) is removed. R_(TH) is called the Thevenin's equivalent resistance and Z_(TH) is called the Thevenin's equivalent impedance. By measuring the short-circuit current, I_(SC) flowing through a wire that connects x to Y, the value of R_(TH) (or Z_(TH) ) can be calculated as the ratio of V_(TH) over I_(SC). When calculating the Thevenin's equivalent impedance, the phasor values are to be used.
The series combination of V_(TH) and R_(TH) (or Z_(TH) ) is the equivalent circuit of the black box. By equivalent, it means the voltage across and current through any circuit element that is connected between terminals x and Y of the black box will be the same as the case when that circuit element is connected in series with R_(TH) (or Z_(TH) ) and V_(TH). The theorem is valid provided that the circuit inside the "black box" is linear. The load resistor, R_(L) (or load impedance, Z_(L) ) however, may not be linear.
Figure 1: Thevenin equivalent circuit
Another important theorem for circuit analysis is the superposition theorem. For a linear circuit, the total effect of several causes acting simultaneously is equal to
