Impedance problem - part (a) Imag. Axis Z WL φ Real Axis R The impedance of a series RC circuit is illustrated in the phasor diagram above. If R = 25 Ω, L = 5.2 mH, and w = 2π × 103 rad/s, What is the magnitude Z of the impedance (in ohms)? (Use 2 significant digits in your answer.)
