Question

In a typical tension test, a dog-bone-shaped specimen is pulled in a machine. During the test, the force F needed to pull the specimen and the length L of a gauge section are measured. This data is used for plotting a stress-strain diagram of the material. Two definitions, engineering and true, exist for stress and strain. The engineering stress σe and strain εe are defined by: σe = F / Ao εe = (L - Lo) / Lo where Lo and Ao are the initial gauge length and the initial cross-section area of the specimen, respectively. The true stress σt and strain εt are defined by: σt = F / Ao εt = ln(L / Lo) The following are the measurements of force and gauge length from a tension test with an aluminum specimen. The specimen has a round cross-section with a radius of 6.4mm (before the test). The initial gauge length is Lo = 25mm. a. Use the data to calculate and print the engineering and the true stress-strain curves. b. Plot the engineering and true stress-strain curves, both on the same plot of the material. Label the axes and label the curves. Units: When the force is measured in Newtons (N), and the area is calculated in m², the units of stress are Pascals (Pa). F (N) 0 13345 26689 40479 42703 43592 44482 44927 45372 L (mm) 25 25.037 25.073 25.113 25.122 25.125 25.132 25.144 25.164 F (N) 46276 47908 26689 49035 50265 53213 44482 56.161 L (mm) 25.208 25.409 25.073 25.646 26.084 25.125 27.398 29.150 Requirements: Use a vector of structures to store the force F and the gauge length L from the table. Use two functions, E_stress_strain and T_stress_strain, to calculate the engineering and the true stress-strain, respectively. Please write code in C++ and follow all instructions.

          In a typical tension test, a dog-bone-shaped specimen is pulled in a machine. During the test, the force F needed to pull the specimen and the length L of a gauge section are measured. This data is used for plotting a stress-strain diagram of the material. Two definitions, engineering and true, exist for stress and strain. The engineering stress σe and strain εe are defined by:

σe = F / Ao
εe = (L - Lo) / Lo

where Lo and Ao are the initial gauge length and the initial cross-section area of the specimen, respectively. The true stress σt and strain εt are defined by:

σt = F / Ao
εt = ln(L / Lo)

The following are the measurements of force and gauge length from a tension test with an aluminum specimen. The specimen has a round cross-section with a radius of 6.4mm (before the test). The initial gauge length is Lo = 25mm.

a. Use the data to calculate and print the engineering and the true stress-strain curves.
b. Plot the engineering and true stress-strain curves, both on the same plot of the material. Label the axes and label the curves.

Units: When the force is measured in Newtons (N), and the area is calculated in m², the units of stress are Pascals (Pa).

F (N)      0       13345   26689   40479   42703   43592   44482   44927   45372
L (mm)    25      25.037  25.073  25.113  25.122  25.125  25.132  25.144  25.164

F (N)      46276   47908   26689   49035   50265   53213   44482   56.161
L (mm)    25.208  25.409  25.073  25.646  26.084  25.125  27.398  29.150

Requirements:
Use a vector of structures to store the force F and the gauge length L from the table. Use two functions, E_stress_strain and T_stress_strain, to calculate the engineering and the true stress-strain, respectively. Please write code in C++ and follow all instructions.
Show more…
