          2. A rigid, lightweight member ABC is supported by two uniaxially loaded rods as shown
in the figure. ABC was initially horizontal before application of force P = 7 kN. Find the
force in each rod, and calculate the downwards displacements of points A, B and C. The
modulus of elasticity E = 200 GPa for both rods.
$A_A = 85 \text{ mm}^2$
$A_C = 60 \text{ mm}^2$
1.3 m
1.55 m
A
C
B
P = 7 kN
2 m
1 m
