Problem Solving Oscillator J1 BF256B OUT BAT1 4.5 V L 15 nH C2 = ? C1 = ? R = ? $Y_1 = jC_1\omega$ $Y_2 = jC_2\omega$ $Y_3 = \frac{1}{R+j\omega L}$ a) Design an oscillator that operates at a frequency of 200 MHz with the following specifications: Inductance: 15 nH Q factor: 50, Transistor transconductance with $g_m = 20$ mS $R_o = 1/G_o = 100 \Omega$. $g_m = 0.020$ $G_o = \frac{1}{100} = 0.01$ b) For 10% tolerance in inductor, determine the lowest value required for the Q factor of inductor. $|2 -4| = 2(3) - (-5)(1-9)$

Name: problem solving oscillator j1 bf256b out bat1 45 v l 15 nh c2 c1 r y1 jc1omega y2 jc2omega y3 frac1rjomega l a design an oscillator that operates at a frequency of 200 mhz with the foll 95588
Uploaded: 2025-05-08T02:06:33-08:00
Duration: 1 min 35 s
Channel: Andreas Papavassiliou
Description: problem solving oscillator j1 bf256b out bat1 45 v l 15 nh c2 c1 r y1 jc1omega y2 jc2omega y3 frac1rjomega l a design an oscillator that operates at a frequency of 200 mhz with the foll 95588

          Problem Solving
Oscillator
J1
BF256B
OUT
BAT1
4.5 V
L
15 nH
C2 = ?
C1 = ?
R = ?
$Y_1 = jC_1\omega$
$Y_2 = jC_2\omega$
$Y_3 = \frac{1}{R+j\omega L}$
a) Design an oscillator that operates at a frequency of 200 MHz with the
following specifications:
Inductance: 15 nH
Q factor: 50,
Transistor transconductance with $g_m = 20$ mS
$R_o = 1/G_o = 100 \Omega$.
$g_m = 0.020$
$G_o = \frac{1}{100} = 0.01$
b) For 10% tolerance in inductor, determine the lowest value required for the Q
factor of inductor.
$|2 -4| = 2(3) - (-5)(1-9)$
