Q2: The 80-lb block C rests on the uniform 5-Ib bar AB. The cable connecting C to B passes over pulley D. Find the magnitude of the force acting between the block and the bar.
Added by Jason A.
Step 1
Step 1: Set up the equations based on the given information: From the explanation, we have: 2t - n = 30 (Equation 1) p + n = 80 (Equation 2) Show more…
Show all steps
Your feedback will help us improve your experience
Adi S and 86 other Physics 101 Mechanics educators are ready to help you.
Ask a new question
Labs
Want to see this concept in action?
Explore this concept interactively to see how it behaves as you change inputs.
Key Concepts
Recommended Videos
Suman Saurav T.
Find the horizontal and vertical components of force at pin C in terms of the tension in the pulley, in the frame shown below. The frame is connected by pins at A, B, and C. Note: you do not need to separate the pulley from the member BC to solve. The cable running through the pulley connects to member AC at the small hook as shown. (25 pts)
Madhur L.
A $15.0$ -lb block rests on the floor. (a) What force does the floor exert on the block? (b) If a rope is tied to the block and run vertically over a pulley, and the other end is attached to a free-hanging $10.0$ -lb weight, what is the force exerted by the floor on the $15.0-\mathrm{lb}$ block? (c) If we replace the $10.0-1 \mathrm{~b}$ weight in part (b) with a $20.0-\mathrm{lb}$ weight, what is the force exerted by the floor on the 15.0-lb block?
