00:01
In the given case, the diode will conduct, diode will conduct during the negative potential path.
00:12
So, in that case, t by 2 to t half and v naught will look like the graph, this graph, this will be the graph.
00:34
Here t, here like this, then like this.
00:48
Here we will have t by 2, then t here, minus 20 volts here.
01:00
So, this is what it will look like.
01:02
Here we will have 0 and v naught.
01:08
And in the case of full period, full period, the dc level, dc level will be equal to vdc equals minus 0 .318 v amp, which will be equal to minus 0 .318 multiplied to, multiplied to 20, which will be equal to minus 6 .36 volts.
01:47
Now, following the equation, the vdc will approximately be equal to 0 .318 v amp minus vt, where v amp is very great, very larger than vt...
