Question 1 Consider the preferred hole basis charts. Is the following statement true or false: The lower limit of the hole tolerance is always equal to the nominal size of the joint. True False Question 2 A steel dowel pin of 10 mm nominal diameter has a note indicating, "ISO 2338 (diameter = h7 tolerances)." What is the lower limit of size for the pin diameter? Question 3 A shaft needs to be machined to make multiple diameters possible and the various mating gears are also being machined. Which ANSI B4 tables should be used: Diameters of size Preferred shaft basis Limits of diameters Preferred hole basis Question 4 A door hinge has a nominal .25 inch pin (shaft). The pin is manufactured to have a special head and the same company manufactures the hinge hole. Assume a "Free running fit" is appropriate. What is the range of possible clearance between the pin and mating hole? Identify the lower limit and the upper limit in the list below.
Added by Christopher P.
Close
Step 1
Step 2: For Question 1: - The statement is: "The lower limit of the hole tolerance is always equal to the nominal size of the joint." - In the preferred hole basis system, the hole's lower limit is typically set to the nominal size, and the shaft is machined to Show more…
Show all steps
